Deskripsi Load Cell CAS SBA
SBA Imperial S-beam load cell, 50lb – 20klb
FEATURES
● NTEP III 5,000 single (Handbook 44)
● NTEP IIIL 10,000 single (Handbook 44)
● Compatible with other sources
● Protection class IP65
OPTIONS
● NTEP III 5,000M approved
● NTEP IIIL 10.000S approved
SPECIFICATIONS
|
Max. capacity |
kgf |
50,75,100,150,200,250,250,300,500,750 1k,1.5k,2k,2.5k,3k,5k,7.5k,10k,15k,20k |
|
| Rated output
Zero balance |
mV/V mV/V |
3.0 ± 0.0075 0 ± 0,03 |
|
| Accuracy class |
|
D3 |
A5(III5,000S/IIIL10,000S) |
| Combined error
Repeatability Creep for 30 min. Temperature effect on Zero Value Output value |
% % %
%/10°C %/10°C |
0.03 0.01 0.03
0.028 0.014 |
0.025 0.01 0.017
0.014 0.011 |
| Excitation
Recommended Maximum Resistance Input Output Insulation |
V V
Ω Ω MΩ |
10 15
350 ± 3,5 350 ± 3.5 >2.000 |
|
| Compensated temperature range
Operating temperature range |
°C °C |
-10 to + 40 -30 to + 80 |
|
Material
Nickel plated steel
Cable
Braided shield 4-wire round cable
With P.V.C-jacket
|
Model |
capacity |
A |
B |
C |
D |
E |
F |
|
SBA-50lb,100lb,150lb,200lb, |
50lb,75lb,100lb,150lb,200lb |
2.0(50.8) |
2.5(63.5) |
0.5(12.7) |
0.6(15.3) |
0.39(9.75) |
¼-28UNF |
|
SBA-250lb,300lb |
250lb,300lb |
2.0(50.8) |
3.0(76.2) |
0.5(12.7 |
0.8(20.0) |
0.47(12) |
3/8-24UNF |
|
SBA-500lb,750lb,1klb,1,5klb,2klb |
500lb,750lb,1klb,1,5klb,2.5klb,3klb |
2.0(50.8) |
3.0(76.2)
|
0.75(19) |
1.06(27) |
0.5(12.6) |
½-20UNF |
|
SBA-25KLB,3klb |
2.5klb,3klb |
2.0(50.8) |
3.0(76.2) |
1.0(25.4) |
1.3(33) |
0.5(12.6) |
1/2-20UNF |
|
SBA-5klb |
5klb |
3.03(77.0) |
4.25(108.0) |
1.0(25.4) |
1.3(33) |
0.75(19) |
¾-16UNF |
|
SBA-7.5klb,10klb |
7,5klb,10klb |
3.5(77.0) |
4.75(120.65) |
1.0(25.4) |
1.3(33) |
0.87(22) |
¾-16UNF |
|
SBA-15klb |
15klb |
4.0(101.6) |
6.5(165.1) |
1.25(1.75) |
1.55(39.35) |
1.18(30) |
1-14UNF |
|
SBA-20klb |
20klb |
5.0(127.0) |
7.0(177.8) |
2.0(50.8) |
2.30(58.4) |
1.26(32) |
1.1/4-12UNF |
